NHY-F0054
NHY
Our custom CNC machined precision pipe fittings are high-performance mechanical components engineered for reliable connection, direction change, flow distribution, and sealing in industrial piping, hydraulic, pneumatic, and sanitary fluid systems. As core components of pipeline infrastructure, these fittings cover a full range of types including elbows, tees, couplings, adapters, flanges, and custom non-standard geometries, all produced via advanced CNC turning, milling, threading, and precision grinding processes. Manufactured from premium materials such as carbon steel, stainless steel, brass, and alloy steel, each pipe fitting delivers ultra-tight dimensional tolerances (≤0.005mm), exceptional pressure resistance, and long-term corrosion stability, ensuring leak-free operation even in harsh industrial environments. Fully customizable in size, connection type, material, and surface treatment, our pipe fittings cater to non-standard piping system requirements where standard off-the-shelf components fail to meet pressure, sealing, or dimensional needs, supporting diverse industries from oil & gas to food & beverage.
| Parameter Name | Specifications | Tolerance/Range | Optional/Notes |
| Product Type | Industrial Precision Custom Fitting | N/A | Matches non-standard fasteners & turning parts |
| Material | 304/316 SS, Carbon Steel, Brass, Al Alloy | N/A | Custom material for special industry needs |
| Precision | CNC Precision Turning & Machining | ±0.005mm (adjustable) | Meets precision turning part standards |
| Surface Treatment | Zinc Plating, Nickel Plating, Polishing, Passivation | N/A | Sandblasting for enhanced corrosion resistance |
| Size Range | Customizable per drawings/samples | M1-M80 or non-standard dimensions | Compatible with non-standard fastener sizes |
| MOQ | 100 Pcs | Negotiable for bulk orders | Bulk discount for fastener & fitting combo orders |
| Service | OEM/ODM, Custom Design, Sample Testing | N/A | 24/7 technical support & after-sales service |
A leading oil & gas operator integrated our carbon steel high-pressure pipe fittings into their onshore crude oil transmission pipelines. The precision-machined threaded connections withstood 10,000 PSI operating pressure, eliminating pipeline leakage and reducing unplanned maintenance shutdowns by 40%, while the corrosion-resistant coating extended the pipeline service life by 35%.
A top beverage manufacturer deployed our 316L stainless steel sanitary pipe fittings in their juice pasteurization lines. The electropolished, crevice-free design eliminated bacterial contamination risks, meeting strict FDA food safety standards, reducing product recall risks to zero, and improving production efficiency by 28%.
Ultra-tight dimensional tolerance and precision-machined sealing surfaces eliminate fluid leakage, ensuring reliable operation in high-pressure piping systems and reducing maintenance downtime.
Supports custom geometries (elbows, tees, crosses, adapters) and connection types (threaded, welded, socket weld, flanged) to meet any piping system layout requirement.
Offers carbon steel for high strength, stainless steel for corrosion resistance, brass for conductivity, and alloy steel for extreme temperature applications, tailored to specific operating environments.
Engineered to withstand operating pressures up to 15,000 PSI and extreme temperatures from -200°C to 650°C, ideal for oil & gas, chemical, and aerospace piping systems.
100% dimensional inspection via CMM
Material certification (RoHS, mill test reports)
Fatigue and torque testing for critical applications
ISO 9001, ITAF 16949, ISO14001
